▷Specification

◼ Parameters: Oil on water

◼ Detector Type: Fluorometer Methodology

1. Light emission at Xenon flash tube

2. Fluorescent stimulation of surface oil

3. Fluorescence reflected from oil is detected by the light detector.

4. Once oil is identified, the flash is repeated several times to verify the first detection.

5.Once the detection is clear, report the detection to the base station immediately.

◼ Range: 0.2m ~ 5m

◼ Power: 100/200/220/230/240 VAC, 24VDC(±12V)

◼ Option: Solar battery

◼ 20cm x 30cm x 38cm, approx. 13kg

▷Features

◼ Non-Contact sensor

◼ Full Automation: Sensors, power supplies, and communications all rolled into one

◼ High sensitivity, accuracy, and reliable data due to fluorescence measurements

◼ Low contamination concerns due to the Non-contact sensor. easy installation and maintenance

▷Applications

Oil on Water Detection: Crude, Lube, Hydraulic, Jet/Aviation, Diesel, Fuel Oil, Turbine, Transformer, and Many Others (contact factory to inquire about types of oil detected)
